SL500 Outdoor Motion Sensor for Lighting Solutions

The SL500 by RAB is an adaptable outdoor motion sensor designed to retrofit lanterns for sensor operation, ideal for electrical distributors and lighting solution providers. It controls lighting loads up to 500 watts incandescent or 250 watts fluorescent at 120 volts AC, making it suitable for residential and commercial lighting applications. The sensor features a wide 180° detection pattern with tilt-down adjustment, providing comprehensive coverage for security and convenience lighting. It is compatible with most electronic ballasts but not with instant start ballasts.

Specifications

• Voltage: 120 volts AC, 60 Hz
• Power Consumption: One watt
• Relay On/Off Model: Controls 500 watts incandescent or 250 watts fluorescent at 120V
• Switching Capacity: 240 watts when lights are mounted to sensor; 500 watts incandescent or 240 watts fluorescent for remotely mounted lighting
• Time Adjustment: 5 seconds to 15 minutes
• Quick Test Time: 5 seconds for fast installation, works day or night
• Detection Pattern: 180° with tilt-down adjustment
• Manual Override: Double flip wall switch logic prevents activation by brief power outages, resets after 8 hours or at dawn
• Surge Protection: Withstands up to 3000 volts
• RF Immunity: Circuits fully shielded for maximum radio frequency immunity
• UL Listing: Suitable for wet locations
• Weight: 1.7 lbs
• Dimensions: 6 5/8" x 6 5/8" x 10" maximum length with extender (approximate)
• Color: White
• Warranty: 5-year sensor warranty

Features

• Adapts lanterns to sensor operation, fitting small or large size lanterns
• 180° wide detection with tilt-down adjustment for precise coverage
• Photoelectric control to deactivate lights during daylight, fully adjustable for 24-hour operation or custom applications
• LED detection indicator glows red day and night for “on guard” deterrence
• Protected manual override with auto reset after 8 hours or at dawn
• Quick installation with 5-second test time and auto test logic
• Compatible with most electronic ballasts (excluding instant start ballasts)
• Double weatherproofing and rugged construction for outdoor use
