Description
SIEMENS SLVBR3650IG Fusible Bus Plug 600V 400A
The Siemens SLVBR3650IG is a heavy-duty fusible bus plug designed for use in electrical distribution systems requiring reliable protection and isolation. This 3-pole, 3-wire bus plug operates at 600 volts with a 400-ampere rating and features an isolated ground for enhanced safety. It is suited for integration within busway systems, supporting electrical distributors and switchgear suppliers in delivering robust lighting solutions and wire and cable management.
Specifications
- Manufacturer: Siemens
- Manufacturer Part #: SLVBR3650IG
- Voltage Rating: 600V
- Maximum Ampere Rating: 400A
- Configuration: 3-Pole, 3-Wire
- Ground Designation: Isolated Ground (IG)
- Enclosure Type: Circuit Breaker Enclosure
- IP Rating: IP40
- Dimensions (W x H x L): 21 in x 24 in x 43 in
- Product Weight: 145 lbs
- Orientation: Vertical (Riser)
- UPC: 783643550964
Features
- Heavy Duty Fusible Switch for busway applications
- Isolated ground design for enhanced electrical safety
- IP40 rated enclosure providing basic protection against solid objects
- Vertical (riser) mounting orientation suitable for busway riser installations
- Supports 3-pole, 3-wire configuration for 600V systems
