SIEMENS NGB2B080V BRKR NGB 80A 2P 480Y 25K NO LUG BULK
SKU: #398050
Part: #NGB2B080V
UPC: 783643555273
SIEMENS NGB2B080V BRKR NGB 80A 2P 480Y 25K NO LUG BULK
SKU: #398050
Part: #NGB2B080V
UPC: 783643555273
Description
SIEMENS NGB2B080V Breaker 80A 2 Pole 480Y Lighting Solutions
The SIEMENS NGB2B080V is a 2-pole circuit breaker designed for use in Siemens panelboard and switchboard applications. This breaker is suitable for electrical distributors and switchgear suppliers requiring reliable protection and switching for lighting and electrical distribution systems. It is rated for 80 amps with a 25kA interrupting capacity, supporting 480Y/277V AC systems, ensuring safety and compliance in commercial and industrial installations.
Specifications
- Manufacturer: Siemens
- Manufacturer Part #: NGB2B080V
- Number of Poles: 2
- Amperage Rating: 80A
- Voltage Rating: 480Y/277V AC
- Interrupting Rating: 25,000 RMS symmetrical amperes (25kA)
- Product Weight: 1.1020 lbs
- UPC: 783643555273
Features
- Load side lugs supplied as standard for secure wire connections
- Compatible with copper and aluminum conductors with specified torque settings
- UL489 and IEC 60947-2 certified for global compliance
- Designed exclusively for Siemens panelboard and switchboard designs
- Includes retainer clips for secure mounting
- Installation requires insulating material with minimum dielectric strength of 600 V/mil when mounted on metal surfaces
