SIEMENS NGB2B060V BRKR NGB 60A 2P 480Y 25K NO LUG BULK
SKU: #398052
Part: #NGB2B060V
UPC: 783643555259
SIEMENS NGB2B060V BRKR NGB 60A 2P 480Y 25K NO LUG BULK
SKU: #398052
Part: #NGB2B060V
UPC: 783643555259
Description
SIEMENS NGB2B060V Breaker 60A 2-Pole Electrical Distributor Circuit Breaker
The SIEMENS NGB2B060V is a 60 amp, 2-pole circuit breaker designed for use in Siemens panelboard and switchboard applications. It serves as a reliable protective device for electrical distribution systems, suitable for commercial and industrial environments. This breaker is part of Siemens' NGB series, offering consistent performance and compatibility with Siemens certified components.
Specifications
- Manufacturer: Siemens
- Manufacturer Part #: NGB2B060V
- Number of Poles: 2
- Current Rating: 60 Amps
- Interrupting Ratings: UL489 rated for 25 kA at 480Y/277 VAC
- Product Weight: 1.5630 lbs
- UPC: 783643555259
Features
- Load side lugs supplied as standard for secure wire connections
- Compatible with copper and aluminum conductors, supporting wire sizes from 14 AWG to 2/0 AWG depending on amp rating
- Meets UL489 and IEC 60947-2 standards for safety and performance
- Designed for panelboard mounting with Siemens certified components only
- Includes retainer clips for secure installation
- Recommended torque specifications for wire connections ensure reliable electrical contact
