SIEMENS NGB2B060BNAV Breaker 60A 2P Electrical Distributor

The SIEMENS NGB2B060BNAV is a 60 Amp, 2-pole molded case circuit breaker designed for panelboard and switchboard applications. It is suitable for use by electrical distributors and switchgear suppliers requiring reliable protection in electrical distribution systems. This breaker supports 480Y volts operation with a 25kA interrupting rating, making it appropriate for a range of commercial and industrial electrical installations.

Specifications

• Manufacturer: Siemens
• Manufacturer Part Number: NGB2B060BNAV
• Number of Poles: 2
• Continuous Current Rating: 60 Amps
• Voltage Rating: 480Y Volts
• Interrupting Rating: 25,000 Amps
• Product Weight: 2.756 lbs
• UPC: 040892165012

Features

• Molded case construction for enhanced durability and safety
• Panelboard mount suitable for Siemens certified panelboards and switchboards
• Load and line lugs included for copper/aluminum wire connections (60/75¬∞C)
• HACR rated for use with heating, air conditioning, and refrigeration equipment
• Compact 2-pole design with 1-inch width per pole for efficient panel space utilization
• Installation requires insulating material with minimum dielectric strength of 600 V/mil when mounted on metal surfaces
• Compatible with Nut Keeper Kit TNKG3 for secure terminal connections
