SIEMENS NGB2B035V Breaker 35A 2 Pole 480Y

The Siemens NGB2B035V is a 2-pole circuit breaker designed for panelboard mounting, providing reliable protection in electrical distribution systems. This breaker is suitable for use in Siemens panelboard and switchboard designs, making it a key component for electrical distributors and switchgear suppliers focusing on safe and efficient power management. It supports wire connections with copper and aluminum conductors, ensuring compatibility with standard wire and cable sizes.

Specifications

• Manufacturer: Siemens
• Manufacturer Part #: NGB2B035V
• Number of Poles: 2
• Ampere Rating: 35A
• Voltage Rating: 480Y/277 VAC
• Interrupting Rating: 25 kA RMS symmetrical amperes
• Product Weight: 1.5630 lbs
• UPC: 783643555211

Features

• Includes load-side lugs as standard for secure wire termination
• Compatible with copper and aluminum conductors, supporting wire sizes from 8 AWG to 2/0 AWG depending on amp rating
• Global rated for UL, CSA, NOM, and IEC standards ensuring broad compliance
• Designed for use exclusively with Siemens certified components in panelboard and switchboard applications
• Compact design with 1 inch width per pole for efficient panel space utilization
• Torque specifications for lug connections ensure reliable electrical and mechanical performance
