SIEMENS NGB1C080B Breaker 1P 80A 347V 14KA Molded Case Circuit Breaker

The Siemens NGB1C080B is a single-pole molded case circuit breaker designed for panelboard mounting in electrical distribution systems. It is suitable for use in lighting solutions, wire and cable protection, and as part of switchgear assemblies. This breaker provides reliable overcurrent protection for 347V applications with a continuous current rating of 80 amperes and an interrupting capacity of 14kA, meeting the requirements of electrical distributors and contractors.

Specifications

• Manufacturer: Siemens
• Manufacturer Part Number: NGB1C080B
• Number of Poles: 1
• Continuous Current Rating: 80A @ 40¬∞C
• Voltage Rating: 347V AC
• Interrupting Capacity: 14kA RMS symmetrical
• Panelboard Mount Type: NGB Frame
• Product Weight: 1.6760 lbs
• UPC: 040892058796

Features

• Thermal-magnetic trip unit providing standard overcurrent protection
• Load and line lugs included as standard for easy installation
• HACR rated for use with heating, air conditioning, and refrigeration equipment
• Suitable for copper and aluminum conductors with 60/75¬∞C wire rating
• Compact 1-inch width per pole for efficient panelboard space utilization
• Designed exclusively for use in Siemens panelboards and switchboards with certified components
• Compliance with CSA and UL standards for safety and performance
