SIEMENS NGB1B110V BREAKER NGB 1P 110A 347V 14KA LD LGBULK
SKU: #398030
Part: #NGB1B110V
UPC: 783643555150
SIEMENS NGB1B110V BREAKER NGB 1P 110A 347V 14KA LD LGBULK
SKU: #398030
Part: #NGB1B110V
UPC: 783643555150
Description
SIEMENS NGB1B110V Breaker 110A 347V - Circuit Breaker
The SIEMENS NGB1B110V is a 1-pole circuit breaker designed for panelboard and switchboard applications. It is intended for use with Siemens certified components, providing reliable overcurrent protection in electrical distribution systems. This breaker is suitable for electrical distributors and switchgear suppliers seeking robust lighting solutions and wire and cable protection at 110 amps and 347 volts AC.
Specifications
- Manufacturer: Siemens
- Manufacturer Part #: NGB1B110V
- Number of Poles: 1
- Rated Current: 110 Amps
- Voltage Rating: 347 Volts AC
- Interrupting Rating: 14 kA RMS symmetrical amperes
- Product Weight: 0.7760 lbs
- UPC: 783643555150
Features
- Load side lugs supplied as standard for ease of wiring
- Compatible with Siemens NGB panelboards and switchboards
- UL489 and IEC 60947-2 certified for global application
- Supports copper and aluminum wire connections with torque specifications
- Includes retainer clips for secure installation
- Designed for use with 60/75ºC wire
