SIEMENS NGB1B100V Breaker 1P 100A 347V - Electrical Circuit Breaker

The SIEMENS NGB1B100V is a single-pole circuit breaker designed for panelboard and switchboard applications. It provides reliable overcurrent protection with a 100 ampere rating and a voltage capacity of 347 volts AC. This breaker is suitable for use by electrical distributors and switchgear suppliers in commercial and industrial electrical systems.

Specifications

• Manufacturer: Siemens
• Manufacturer Part #: NGB1B100V
• Number of Poles: 1
• Amperage Rating: 100 A
• Voltage Rating: 347 V AC
• Interrupting Rating: 14 kA RMS symmetrical amperes
• Product Weight: 0.7760 lbs
• UPC: 783643555143

Features

• Load side lugs supplied as standard for easy wiring
• Compatible with Siemens certified panelboards and switchboards only
• UL489 and IEC 60947-2 compliant with global ratings (UL / CSA / NOM / IEC)
• Designed for use with copper and aluminum wire sizes per Siemens specifications
• Includes retainer clips for secure installation

Downloads & Links

• Spec Sheet
• Spec Sheet
• Spec Sheet
