SIEMENS NGB1B035V Breaker 35A 347V 1 Pole

The SIEMENS NGB1B035V is a single-pole circuit breaker designed for panelboard and switchboard applications, providing reliable overcurrent protection at 35 amps and 347 volts AC. As a product from a leading electrical distributor and switchgear supplier, it is engineered to meet UL489 and IEC 60947-2 standards, ensuring compatibility with Siemens certified components in electrical distribution and lighting solutions.

Specifications

• Manufacturer: Siemens
• Manufacturer Part #: NGB1B035V
• Number of Poles: 1
• Rated Current: 35 Amps
• Voltage Rating: 347 Volts AC
• Interrupting Rating: 14 kA RMS symmetrical amperes
• Product Weight: 0.7760 lbs
• UPC: 783643555068

Features

• Load-side lugs supplied as standard
• Compatible with 60/75°C copper or aluminum wire
• Torque lug rating: 55 inch-lbs (6.2 Nm) for wire sizes #3 – 2/0 AWG aluminum and #4 – 1/0 AWG copper
• Global rated for UL, CSA, NOM, and IEC standards
• Includes retainer clips for secure mounting
• Intended for use exclusively in Siemens panelboard and switchboard designs
