SIEMENS LDK3G100L Molded Case Circuit Breaker 3P 600Y 100A

The Siemens LDK3G100L is a molded case circuit breaker designed for industrial and commercial electrical distribution applications. It is suitable for use by electrical distributors and switchgear suppliers requiring reliable protection and control in lighting solutions, wire and cable systems, and general power distribution. This 3-pole breaker operates at 600Y volts with a 100 amp continuous current rating and is intended for global non-interchangeable applications.

Specifications

• Manufacturer: Siemens
• Manufacturer Part #: LDK3G100L
• Frame: 150A
• Number of Poles: 3
• Voltage Rating: 600Y
• Current Rating: 100A
• Interrupt Rating: 18kA
• Frequency Rating: 50/60 Hz
• Connection: Line & Load Standard (CU/AL) Lugs
• Material: Molded Case Circuit Breaker
• Operating Temperature: 40°C
• Product Weight: 1.0010 lbs
• Application: Global Non-Interchangeable

Features

• Non-interchangeable trip unit design compliant with UL 489 for reverse feed applications
• Factory assembled with standard line and load connectors for ease of installation
• Thermal-magnetic trip unit suitable for DC and AC applications
• Compact dimensions with 3.7 inches width, facilitating integration into switchgear assemblies
• HACR rated for compatibility with heating, air conditioning, and refrigeration equipment
