SIEMENS HED41B080 BRKR HED4 1P 480V 80A Molded Case Circuit Breaker

The Siemens HED41B080 is a standard 1-pole molded case circuit breaker designed for use in electrical distribution systems requiring reliable overcurrent protection. Rated for 80 amps at 480 volts AC, this breaker is suitable for industrial and commercial applications. It is part of the ED frame series, providing compatibility with Siemens panelboards, switchboards, and enclosures. The breaker supports 50/60 Hz frequency and features a 25KAIC interrupt rating, meeting CSA and UL safety standards. This product is ideal for electrical distributors and switchgear suppliers seeking dependable circuit protection solutions.

Specifications

• Manufacturer: Siemens
• Manufacturer Part #: HED41B080
• Application: Standard 40C Breaker
• Frame: ED
• Number of Poles: 1
• Voltage Rating: 480V AC
• Current Rating: 80A
• Frequency Rating: 50/60 Hz
• Interrupt Rating: 25KAIC
• Operating Temperature: 40°C
• Dimensions (W x H x L): 1 in x 5 in x 6 in
• Product Weight: 1.27 lbs
• Actuator: Varying
• Enclosure: Varying
• UPC: 783643209916

Features

• Single-pole design for branch circuit protection
• High interrupting capacity of 25KAIC ensures safe fault clearing
• Compatible with Siemens ED frame panelboards and switchgear
• Manual operation with ON, OFF, and TRIP positions and PUSH-TO-TRIP test button
• Mounting hardware and wire connectors available separately for flexible installation
• CSA Certified and UL Listed for use in North American electrical systems
