SIEMENS ED63S100ALT1A02 Breaker ED 3P 100A 25KA Molded Case Switch

The SIEMENS ED63S100ALT1A02 is a 3-pole molded case switch designed for circuit disconnect applications. It is suitable for use in electrical distribution systems, providing reliable protection and control. This device is ideal for electrical distributors, lighting solutions, wire and cable management, and switchgear suppliers requiring a robust circuit disconnect switch with a 100A rating and a 25kA interrupt rating. The switch includes line/load lugs installed for ease of connection and is compatible with various enclosures.

Specifications

• Manufacturer: Siemens
• Application: Molded Case Switch
• Frame: ED
• Number of Poles: 3
• Interrupt Rating: 25KAIC
• Frequency Rating: 50/60 Hz
• Operating Temperature: 40°C
• Connection: Line/Load lugs installed
• Dimensions (W x H x L): 7.0 in x 6 in x 4.0 in
• Product Weight: 4.2 lbs
• Enclosure: Varying
• Actuator: A02QT0R3 Accessory
• UPC: 783643112087
• Manufacturer Part #: ED63S100ALT1A02

Features

• Self-protective instantaneous element for circuit protection (per Siemens catalog details)
• Line and load lugs pre-installed for simplified wiring
• Compatible with multiple mounting enclosures and accessories
• Designed for use in panelboards, switchboards, and individual enclosures
• Meets applicable UL and CSA standards for molded case switches and circuit breakers
• Manual operation with ON, OFF, and TRIP positions; PUSH-TO-TRIP button available on breakers (not on switches)
• Supports operation at 50/60 Hz frequency with 25kA interrupt rating for reliable fault clearing
