SIEMENS ED63B125LAESB Circuit Breaker 600V 125A 3-Pole

The SIEMENS ED63B125LAESB is a 3-pole molded case circuit breaker designed for electrical distribution and protection in industrial and commercial applications. It is rated for 600V AC operation with a continuous current rating of 125A and is suitable for use by electrical distributors and switchgear suppliers requiring reliable circuit protection up to 600 volts. The breaker features line/load lugs installed for secure connection and includes a 24V auxiliary switch actuator accessory.

Specifications

• Manufacturer: Siemens
• Manufacturer Part #: ED63B125LAESB
• Application: Standard 40¬∞C Breaker
• Frame: ED
• Number of Poles: 3
• Voltage Rating: 600V AC
• Current Rating: 125A
• Interrupt Rating: 18KAIC
• Frequency Rating: 50/60 Hz
• Operating Temperature: 40¬∞C
• Connection: Line/Load lugs installed
• Actuator: S07ED62A Accessory (24V Auxiliary Switch)
• Dimensions (W x H x D): 4.56 in x 6.35 in x 3 in
• Product Weight: 4.806 lbs
• Enclosure: Varying
• UPC: 887621407131

Features

• Standard 40¬∞C ambient rating for reliable performance
• Line and load lugs factory-installed for ease of wiring
• High interrupting capacity of 18KAIC for circuit protection
• Compatible with Siemens ED frame accessories and modifications
• Compact dimensions facilitate integration into switchgear and panelboards
