SIEMENS ED63A002AREVA BREAKER ED 3P 2A 600V LUGS-ETI AREVA TST Molded Case Circuit Breaker

The Siemens ED63A002AREVA is a 3-pole molded case circuit breaker designed for use in electrical distribution and switchgear applications. It is suitable for protecting electrical circuits up to 600V with a 2 ampere rating. This breaker is ideal for use by electrical distributors and lighting solutions providers requiring reliable wire and cable protection and control in commercial and industrial environments. The breaker features a thermal-magnetic trip unit and is compliant with UL489 and CSA C22.2 No. 5 standards, ensuring safe and efficient operation in demanding electrical systems.

Specifications

• Manufacturer: Siemens
• Manufacturer Part #: ED63A002AREVA
• Frame: ED
• Number of Poles: 3
• Interrupt Rating: 18 KAIC
• Voltage Rating: 600 V
• Operating Temperature: 40¬∞C
• Dimensions (W x H x L): 3.0 in x 5 in x 6 in
• Product Weight: 3.87 lbs
• Actuator Type: Varying
• Enclosure Type: Varying
• UPC: 040892285888

Features

• Non-interchangeable trip unit compliant with UL 489 / CSA C22.2 No. 5 requirements for reverse feed applications
• Thermal-magnetic trip mechanism providing reliable overcurrent protection
• Compatible with copper and aluminum wire connectors meeting UL486A and UL486B standards
• Designed for installation in individual enclosures, panelboards, and switchboards
• Includes push-to-trip button for manual testing of trip functionality
• Load terminals designed for secure wire connection with torque specifications provided on nameplate
• Suitable for 3-phase electrical systems and DC applications with proper wiring configuration
