SIEMENS ED62M090 BRKR ED6 2P 600V 90A 50C Molded Case Circuit Breaker

The Siemens ED62M090 is a molded case circuit breaker designed for electrical distribution and protection in industrial and commercial applications. Calibrated for 50°C operation, this 2-pole breaker supports voltages up to 600V AC at 400 Hz frequency and offers an interrupt rating of 18kAIC, making it suitable for reliable circuit protection in demanding environments. It is ideal for use by electrical distributors and switchgear suppliers requiring robust, precision-calibrated circuit protection solutions.

Specifications

• Manufacturer: Siemens
• Frame: ED
• Number of Poles: 2
• Voltage Rating: 600 V AC
• Frequency Rating: 400 Hz
• Current Rating: 90 A
• Interrupt Rating: 18 KAIC
• Operating Temperature: 50¬∞C
• Dimensions (HxWxL): 7 in x 3 in x 6 in
• Product Weight: 2.5 lbs
• Application: Calibrated for 50¬∞C Application
• Actuator: Varying
• Enclosure: Varying
• UPC: 783643003804

Features

• Non-interchangeable trip unit design typical of ED frame breakers for enhanced safety and compliance
• Thermal-magnetic trip unit technology for reliable overload and short circuit protection
• Compact design suitable for panelboards, switchboards, and individual enclosures
• Designed and tested to meet UL 489 and CSA C22.2 No. 5 standards
• Suitable for use with 60¬∞C or 75¬∞C wiring per NEC and Canadian Electric Code guidelines
• Manual operation includes ON, OFF, and TRIP handle positions with PUSH-TO-TRIP button for testing
• Mounting hardware and wiring accessories available separately for flexible installation
