SIEMENS ED62M080 BRKR ED6 2P 600V 80A 50C Molded Case Circuit Breaker

The Siemens ED62M080 molded case circuit breaker is designed for electrical distribution and protection applications, calibrated specifically for 50°C operating temperature. It is suitable for use by electrical distributors and switchgear suppliers requiring reliable circuit protection up to 600 volts AC and 250 volts DC, with a 2-pole configuration and 80 ampere continuous current rating. This breaker supports a frequency rating of 400 Hz and features an 18KAIC interrupt rating for fault current interruption.

Specifications

• Manufacturer: Siemens
• Manufacturer Part #: ED62M080
• Frame: ED
• Number of Poles: 2
• Voltage Rating: 600 V AC
• Current Rating: 80 A
• Operating Temperature: 50¬∞C
• Frequency Rating: 400 Hz
• Interrupt Rating: 18KAIC
• Dimensions (H x W x L): 7 in x 3 in x 6 in
• Product Weight: 2.5 lbs
• Application: Calibrated for 50¬∞C Application
• Actuator: Varying
• Enclosure: Varying

Features

• Non-interchangeable trip unit design for enhanced safety and compliance with UL 489 and CSA C22.2 No. 5 standards
• Suitable for use in panelboards, switchboards, and individual enclosures
• Thermal-magnetic trip unit providing reliable circuit protection
• Push-to-trip button for manual trip testing and operational verification
• Mounting hardware and wire connectors available separately for flexible installation
• Supports 400 Hz frequency applications, ideal for specialized industrial or commercial electrical systems
