SIEMENS BQ3B04000S01 Circuit Breaker 3-Pole 40A 240V

The Siemens BQ3B04000S01 is a 3-pole circuit breaker designed for 240V electrical systems with a 40 ampere current rating. This breaker is suitable for use in electrical distribution and switchgear applications, providing reliable overcurrent protection. It is calibrated for a maximum ambient temperature of 40°C and is commonly used by electrical distributors and lighting solutions providers to ensure circuit safety and compliance.

Specifications

• Manufacturer: Siemens
• Manufacturer Part #: BQ3B04000S01
• Number of Poles: 3
• Voltage Rating: 240V AC
• Current Rating: 40A
• Interrupt Rating: 10,000 AIC (Amps Interrupting Capacity)
• Product Weight: 1.7 lbs
• UPC: 783643237841

Features

• Common-trip 3-pole design for simultaneous disconnection
• Load side lugs supplied standard; line side lugs available as an option
• Calibrated for 40°C maximum ambient temperature
• CSA Certified and UL Listed for use on 3-phase grounded “B” systems
• Suitable for frequent switching applications including 120V AC fluorescent lighting
• HACR rated for HVAC equipment compatibility
• Factory installed 120VAC shunt trip option available

Downloads & Links

• Spec Sheet
