SIEMENS B250HM BREAKER 50A 2P 120/240V 22K 50C BLH Molded Case Circuit Breaker

The Siemens B250HM is a 2-pole molded case circuit breaker designed for panelboard mounting with INSTA-WIRE technology. It is rated for 50 amps at 120/240 volts AC, providing reliable overcurrent protection in electrical distribution systems. Suitable for use by electrical distributors and switchgear suppliers, this breaker supports a 22,000A interrupting rating and is intended for applications requiring robust circuit protection in residential, commercial, or light industrial environments.

Specifications

• Manufacturer: Siemens
• Manufacturer Part #: B250HM
• Number of Poles: 2
• Amperage Rating: 50A
• Voltage Rating: 120/240V AC
• Interrupting Rating: 22,000A
• Product Weight: 0.7200 lbs

Features

• Panelboard mounting with INSTA-WIRE selection for quick and secure installation
• Common-trip design for simultaneous disconnection of both poles
• HACR rated for use with heating, air conditioning, and refrigeration equipment
• CSA Certified and UL Listed for use with 60/75°C wire (per catalog notes)
• Compact dimensions suitable for standard panelboards (approx. 3 9/16" L × 2 3/8" D × 3" W)
