SHARK4-50W/D10 LED Lighting Fixture

The SHARK4-50W/D10 by RAB is a high-efficiency LED lighting fixture suitable for indoor and outdoor applications, including stairwells, passageways, and low bay lighting. Designed for electrical distributors and lighting solutions providers, this fixture delivers reliable illumination with advanced photometric performance. It operates efficiently within a universal voltage range of 120V to 277V and supports 0-10V dimming for flexible lighting control. Its durable construction and textured, diffuse polycarbonate lens ensure consistent light distribution while maintaining weatherproof integrity.

Specifications

• Manufacturer: RAB
• Model Number: SHARK4-50W/D10
• Input Wattage: 48 watts
• Luminous Output: 6,862 lumens
• Efficacy: 142 lumens per watt
• Color Temperature: 5000 kelvins
• Color Rendering Index (CRI): 86
• Lens Material: Textured, Diffuse Polycarbonate
• Operating Ambient Temperature: Up to 104°F
• Minimum Starting Temperature: -22°F
• Weight: 10 lbs

Features

• Universal voltage driver compatible with 120V-277V, 50/60 Hz
• High lumen output with an efficacy of 142 lm/W for energy efficiency
• 0-10V dimmable driver for adjustable lighting levels
• Durable weatherproof housing suitable for wet locations, ceiling or wall mounted
• Textured, diffuse polycarbonate lens for uniform light distribution
• Wide operating temperature range for reliable performance in various environments
• Complies with National Electrical Code and applicable local codes
• Emergency driver option with battery backup providing 25W power for a minimum of 90 minutes (refer to installation instructions)

Downloads & Links

• Instructions
• LM79
• Spec Sheet
