Series C, J-frame molded case circuit breaker, Factory Sealed, 200A, Two-pole, Without terminals, Non-interchangeable thermal magnetic trip, JDB breaker
SKU: #166710
Part: #JDB2200W
UPC: 786679516133
Series C, J-frame molded case circuit breaker, Factory Sealed, 200A, Two-pole, Without terminals, Non-interchangeable thermal magnetic trip, JDB breaker
SKU: #166710
Part: #JDB2200W
UPC: 786679516133
Description
Series C J-frame Molded Case Circuit Breaker – Circuit Protection
The Eaton Series C J-frame molded case circuit breaker is designed for reliable electrical distribution and branch circuit protection in industrial and commercial applications. This factory-sealed, two-pole breaker with a 200 ampere rating provides thermal magnetic trip functionality to safeguard electrical systems. Suitable for use by electrical distributors and switchgear suppliers, it offers robust protection without terminals and is non-interchangeable, ensuring secure and specific application use.
Specifications
- Manufacturer: Eaton
- Manufacturer Part Number: JDB2200W
- Frame: J
- Amperage: 200 amperes
- Number of Poles: 2
- Interrupt Rating: 65 kiloamps
- Dimensions (W x H x L): 4.13 in x 4.13 in x 4.06 in
- Product Weight: 11.25 lbs
- UPC: 786679516133
Features
- Factory sealed for enhanced reliability and safety
- Non-interchangeable thermal magnetic trip unit for precise circuit protection
- Two-pole design for balanced load interruption
- Compact J-frame size for flexible panel installation
