SEAL8-100/D10 Linear LED Washdown Fixture

The SEAL8-100/D10 by RAB is an economical linear LED washdown fixture designed for use in canopies, loading docks, tunnels, stairwells, and other hard-to-reach areas where relamping is difficult and costly. This fixture is suitable for wet locations and offers reliable lighting solutions for electrical distributors and switchgear suppliers seeking durable, high-performance wire and cable compatible lighting products.

Specifications

• Input Wattage: 98 watts
• Lumens: 11,698 lumens
• Efficacy: 119 lumens per watt
• Color Temperature: 5000 kelvins
• Color Accuracy: 82 CRI
• Lens Material: Diffuse Polycarbonate
• Product Weight: 22.4 lbs
• Minimum Starting Temperature: -20°C (-4°F)
• Maximum Ambient Temperature: 40°C (104°F)
• LED Lifespan: 50,000 hours
• IP Rating: IP65 (dust and water protection)
• Driver Type: Constant Current, Class 2, 120-277V, 50/60Hz
• Power Factor: 99.4% at 120V, 97.3% at 277V
• THD: 9.4% at 120V, 12.1% at 277V

Features

• Impact-resistant polycarbonate housing with stainless steel door clips
• Diffuse polycarbonate lens for low glare and maximum protection
• High-temperature silicone gaskets for weatherproof sealing
• Quick-mount stainless steel snap-on brackets for surface mounting
• V-hook brackets included for chain mounting suspension
• 6 ft, 5-wire cord installed for easy electrical installation
• 0-10V dimming capability
• Mercury and UV free, RoHS-compliant components
• Suitable for damp and wet locations when installed properly
• 5-year limited warranty covering light output, driver, and finish
