SEAL4-50N/D10 LED Linear Washdown Fixture

The SEAL4-50N/D10 by RAB is an economical linear LED washdown fixture designed for industrial and commercial environments such as canopies, loading docks, tunnels, and stairwells. This fixture is engineered to provide reliable, energy-efficient lighting where relamping is difficult and costly. It is suitable for wet locations and offers a durable solution for electrical distributors and lighting solutions providers seeking robust wire and cable compatible lighting products.

Specifications

• Manufacturer: RAB
• Input Wattage: 48 watts
• Lumens: 5,718 lumens
• Efficacy: 118 lumens per watt
• Color Temperature: 4000 kelvins (Neutral)
• Color Accuracy: 84 CRI
• Lens Material: Diffuse Polycarbonate
• Product Weight: 8.0 lbs
• Ambient Temperature Rating: Up to 104°F (40°C)
• Minimum Starting Temperature: -20°C (-4°F)
• Driver Type: Constant Current, Class 2, 120-277V, 50/60Hz
• Power Factor: 99.5% at 120V, 97.2% at 277V
• THD: 8.6% at 120V, 11.6% at 277V
• LED Lifespan: 50,000 hours (L70)
• IP Rating: IP65 for dust and water protection

Features

• Economical linear washdown design ideal for harsh environments
• Impact-resistant polycarbonate housing with stainless steel door clips
• Diffuse polycarbonate lens for low glare and maximum protection
• Quick-mount stainless steel snap-on brackets for surface or suspended mounting
• 0-10V dimming capability
• High-temperature silicone gaskets for weatherproof sealing
• Mercury and UV free with RoHS-compliant components
• Suitable for wet locations and damp environments when installed with Lightcloud Sensor
• Equivalency to 32W 2-lamp T8 fluorescent fixtures
• 5-year limited warranty covering light output, driver performance, and finish
