Description
SEAL4-50/D10 Linear LED Washdown Fixture
The SEAL4-50/D10 by RAB is an economical linear LED washdown fixture designed for demanding environments such as canopies, loading docks, tunnels, and stairwells. This fixture offers reliable, long-lasting illumination with high efficacy and is suitable for applications requiring minimal maintenance and robust protection. It is ideal for electrical distributors, lighting solutions providers, and switchgear suppliers seeking durable, efficient lighting products.
Specifications
- Manufacturer: RAB
- Input Wattage: 49 watts
- Lumens: 5,849 lumens
- Efficacy: 119 lumens per watt
- Color Temperature: 5000 kelvins (cool)
- Color Accuracy: 82 CRI
- Lens Material: Diffuse Polycarbonate
- Ambient Temperature Rating: Up to 104°F (40°C)
- Minimum Starting Temperature: -20°C (-4°F)
- Product Weight: 8.7 lbs
- Driver Type: Constant Current, 120-277V, 50/60Hz
- IP Rating: IP65 for dust and water protection
- L70 Lifespan: 50,000 hours
Features
- Economical linear washdown solution for harsh environments
- Impact-resistant polycarbonate housing with stainless steel door clips
- Diffuse polycarbonate lens providing low glare and maximum protection
- Quick-mount stainless steel snap-on brackets for surface mounting
- V-Hook brackets included for suspended mounting
- 0-10V dimming capability for flexible lighting control
- Suitable for wet locations and damp environments (with Lightcloud Sensor)
- Mercury and UV free, RoHS-compliant components
- 5-year limited warranty covering light output, driver performance, and finish
