Screw-On Wire Connectors P2 Blue Boxed 100 Pack – Wire Connectors

The Screw-On Wire Connectors P2 Blue Boxed 100 Pack by Morris Products provides reliable and quick wire connections suitable for electrical distributors and lighting solutions professionals. Designed for use with wire sizes ranging from 3 #16 AWG to 2 #22 AWG, these connectors facilitate secure splicing without the need for pre-twisting conductors. Ideal for wire and cable applications, they ensure safe and efficient circuit connections with a flame retardant thermoplastic housing.

Specifications

• Color: Blue
• Wire Combinations: Max 3 #16 AWG, Min 2 #22 AWG
• Maximum Voltage: 300V
• Dimensions (inches): A: 0.161, B: 0.276, C: 0.386, D: 0.232, E: 0.693
• Pack Quantity: 100
• Product Weight: 0.0040 lbs
• Manufacturer Part #: 23072

Features

• Flame retardant thermoplastic housing provides excellent electrical insulation
• Threaded, funnel entry guides wire into the connector easily
• Fixed, precise wire spring creates its own thread, eliminating the need for pre-twisting
• Reusable connector threads on or off splice for fast and easy circuit changes
• Sure-grip ribs improve gripping ability and comfort during installation
• Temperature rated at 221°F (105°C) maximum
• Tough UL 94V-2 flame retardant shell resists cracking or breaking under extreme pressure

Downloads & Links

• Spec Sheet
