Features

• Provides excellent adherence with rubber resin adhesive
• Elongates easily for use in uneven surfaces
• Suitable for indoor and outdoor applications
• Made of copper
• Withstands a wide temperature range of 32 to 221 °F (0 to 105 °C)

Specifications

• Manufacturer Catalog Number: 7000031348
• Adhesive Material: Rubber Resin
• Adhesive Type: Velvet
• Application: Electrical Maintenance
• Backing Material: Tinned Copper
• Backing Thickness (Metric): 0.4 mm
• Breaking Strength (Imperial): 22 lb/in
• Color Family (incorporate Product Color): Gray
• Configurability: Not Configurable
• Dielectric Strength (V/mil): Conductive
• Elongation at Break: NA
• High Temperature Rating: 220°F (105°C)
• Insulated: No
• Low Temperature Rating: 32°F (0°C)
• Material: All-Metal Open Weave
• Maximum Operating Temperature (Celsius): 105 Degree Celsius
• Maximum Operating Temperature (Fahrenheit): 266 Degree Fahrenheit
• Operating Temperature Range (Celsius): 0 °C to 105 °C
• Operating Temperature Range (Fahrenheit): 32 °F to 220 °F
• Overall Length (Imperial): 15 ft
• Overall Length (Metric): 4.6 m
• Overall Width (Imperial): 1 in
• Overall Width (Metric): 25.4 mm
• Self-extinguishing: No
• Self-sticking: No
• Suitable for High Voltage: No
• Tape Grade: Premium
• Tape Type: Electrical Shielding
• Total Thickness: 0.4 mm
• UV Resistant: Yes
• Vulcanizing: No

Packaging

• Package Length: 3.15000 in
• Package Height: 1.35000 in
• Package Weight: 0.1300 LBS
