RWLED4T50SFYRG/PCS LED Roadway Lighting

The RWLED4T50SFYRG/PCS is a 50-watt LED roadway lighting fixture designed for efficient and uniform illumination of entrance roadways, collector roads, and single-sided roads. Manufactured by RAB, this product offers a reliable lighting solution with specification-grade optics that meet IES Distribution Type IV standards, ideal for electrical distributors and lighting solutions providers focusing on wire and cable and switchgear applications in outdoor environments. It features a durable die-cast aluminum housing and tempered glass lens, suitable for wet locations and capable of operating in ambient temperatures up to 104°F (40°C).

Specifications

• Manufacturer: RAB
• Input Wattage: 55 watts
• Lumens: 7,127 lumens
• Efficacy: 130 lumens per watt
• Color Temperature: 3000 kelvins (Warm)
• Color Accuracy: 71 CRI
• Lens Material: Tempered Glass
• Ambient Temperature: Up to 104°F (40°C)
• Minimum Starting Temperature: -40°C (-40°F)
• Weight: 32 lbs
• Ingress Protection: IP66 for dust and water
• Vibration Rating: 5G per ANSI C136.31
• Recommended Mounting Height: Up to 15 ft
• Effective Projected Area (EPA): 2.2

Features

• Specification-grade optics with IES Type IV distribution for perimeter and intersection lighting
• Multi-chip, high-output, long-life LEDs with 100,000-hour lifespan
• Superior thermal management with external air-flow fins for enhanced operational life
• Die-cast aluminum housing, lens frame, and mounting arm for durability
• Slipfitter mounting with 180° pivot for installation on 2 3/8" tenon poles
• High-temperature silicone gaskets and formulated finish for long-lasting color and durability
• 120V swivel photocell included, compatible only with 120V supply
• 6kV surge protection tested per IEEE/ANSI C62.41.2
• 3-step MacAdam Ellipse binning for consistent color uniformity
• Buy American Act compliance available upon request

Downloads & Links

• Spec Sheet
• Instructions
