RWLED3T125YRG/PCT LED Roadway Lighting

The RWLED3T125YRG/PCT by RAB is a specification-grade LED roadway lighting fixture designed for efficient, uniform illumination in roadway, general parking, and major road applications. Engineered for durability and performance, it features precision optics with IES Type III distribution, suitable for electrical distributors and lighting solutions providers focusing on wire and cable or switchgear supplier markets requiring high-quality outdoor lighting products.

Specifications

• Manufacturer: RAB
• Input Wattage: 133 watts
• Lumens: 14,119 lumens
• Efficacy: 106 lumens per watt
• Color Temperature: 3000 kelvins (Warm)
• Color Accuracy: 71 Color Rendering Index (CRI)
• Lens Material: Tempered Glass
• Ambient Temperature Rating: 104 degrees Fahrenheit (40°C)
• Minimum Starting Temperature: -40 degrees Celsius (-40°F)
• Product Weight: 32.5 lbs
• IP Rating: IP66 (dust and water resistant)
• Vibration Rating: 5G per ANSI C136.31
• LED Lifespan: 100,000 hours (L70)
• Mounting: Fits standard roadway upsweep arms with universal adaptors for 1", 1 1/4", 1 1/2", and 2" OD pipe

Features

• Specification-grade optics deliver clean, uniform light distributions with minimal glare
• Replaces 350W metal halide fixtures with 125W LED efficiency
• Superior thermal management with external airflow fins for maximum operational life
• 6kV surge protection tested to IEEE/ANSI standards
• 120-277V universal voltage driver with 120-277V twistlock photocell included
• Easy-access electrical compartment for fast, secure wiring
• Industry-leading 5G vibration rating ensures durability in harsh environments
• Wedge mounting option allows field adjustment of +/- 5 degrees tilt for level installation
• RoHS-compliant, mercury and UV free for green technology compliance
• 10-year no-compromise warranty

Downloads & Links

• Instructions
• Spec Sheet
