RWLED3T125NW/BL LED Roadway Light

The RWLED3T125NW/BL is a specification-grade LED roadway lighting fixture designed for efficient and uniform illumination of roadways, general parking, and major roads. It offers high-performance lighting solutions suitable for electrical distributors and lighting solution providers seeking reliable, energy-efficient fixtures. This model features Type III optics for optimal street-side throw and uniform light distribution, making it ideal for use with standard roadway arms and compatible with various mounting options.

Specifications

• Manufacturer: RAB
• Input Wattage: 133 watts
• Lumens: 14,373 lumens
• Efficacy: 108 lumens per watt
• Color Temperature: 4000 kelvins (Neutral)
• Color Accuracy: 70 CRI
• Lens Material: Tempered Glass
• Ambient Temperature Rating: 104 degrees Fahrenheit (40°C)
• Minimum Starting Temperature: -40 degrees Celsius (-40°F)
• Product Weight: 32.5 lbs
• Mounting Compatibility: Fits 1", 1.25", 1.5", and 2" OD roadway arms and slipfitter mounts
• IP Rating: IP66 for dust and water ingress protection
• Vibration Rating: 5G per ANSI C136.31
• LED Lifespan: 100,000 hours (L70)
• Distribution Type: IES Type III
• Surge Protection: 6kV surge suppression per IEEE/ANSI C62.41.2
• Power Factor: 99.4% at 120V, 92.1% at 277V
• THD: 5.1% at 120V, 16.6% at 277V

Features

• Specification-grade optics delivering clean, uniform light distributions
• Replaces 350W metal halide fixtures with significantly lower wattage
• Superior thermal management with external airflow fins for extended life
• Multi-chip, high-output LEDs with 3-step MacAdam Ellipse binning for color consistency
• High durability die-cast aluminum housing with high-temperature silicone gaskets
• Universal adaptors included for multiple arm sizes
• Bi-level operation allowing 50% and 100% output modes
• Easy-access electrical compartment for fast, secure wiring
• Industry-leading 5G vibration rating ensuring reliability in harsh environments
• Mercury and UV free with RoHS-compliant components
• 10-year warranty covering light output, color stability, driver performance, and finish
