RWLED3T105SFRG/PCS LED Roadway Lighting

The RWLED3T105SFRG/PCS by RAB is a specification-grade LED roadway lighting fixture designed for efficient, uniform illumination of roadways, parking areas, and general outdoor spaces. It is suitable for electrical distributors and lighting solutions providers seeking high-performance, durable street lighting options. This product replaces traditional 320W metal halide fixtures with a 105W LED solution, offering enhanced energy efficiency and extended lifespan.

Specifications

• Manufacturer: RAB
• Input Wattage: 109 watts
• Lumens: 12,476 lumens
• Efficacy: 114 lumens per watt
• Color Temperature: 5000 kelvins (Cool)
• Color Accuracy: 70 CRI
• Lens Material: Tempered Glass
• Ambient Temperature Rating: Up to 104°F (40°C)
• Minimum Starting Temperature: -40°C (-40°F)
• Product Weight: 31 lbs
• Distribution Type: Type III IES classification
• IP Rating: IP66 for dust and water protection
• Vibration Rating: 5G per ANSI C136.31
• Lifespan: 100,000 hours (L70)
• Housing: Die-cast aluminum housing, lens frame, and mounting arm
• Mounting: Slipfitter with 180° pivot for 2 3/8" tenon

Features

• Specification-grade optics for clean, uniform light distribution
• Replaces 320W metal halide fixtures with high-efficiency 105W LED
• Superior thermal management with external air-flow fins
• High durability finish with mercury and UV-free, RoHS-compliant components
• 7-step MacAdam Ellipse binning for consistent color quality
• 120V swivel photocell included for enhanced control (compatible only with 120V)
• 6kV surge protection tested per IEEE/ANSI standards
• Easy-access electrical compartment for fast, secure wiring
• Industry-leading 5G vibration resistance for reliable operation
• 10-year warranty covering light output, color stability, driver performance, and finish
