Description
RWLED3T105SFNW/PCS2 LED Roadway Light
The RWLED3T105SFNW/PCS2 by RAB is a specification-grade LED roadway lighting fixture designed for efficient and uniform illumination of roadways, parking areas, and general outdoor spaces. This product is ideal for electrical distributors and lighting solutions providers seeking reliable, high-performance lighting with advanced thermal management and robust construction. It replaces traditional 320W metal halide fixtures with a more energy-efficient 105W LED solution, delivering superior light output and durability suitable for demanding environments.
Specifications
- Manufacturer: RAB
- Manufacturer Part #: RWLED3T105SFNW/PCS2
- Lumens: 12,042 lumens
- Efficacy: 111 lumens per watt
- Input Wattage: 108 watts
- Color Temperature: 4000 kelvins (Neutral)
- Color Accuracy: 72 CRI
- Lens Material: Tempered Glass
- Product Weight: 31 lbs
- Ambient Temperature Rating: Up to 104°F (40°C)
- Minimum Starting Temperature: -40°C (-40°F)
- IP Rating: IP66 for dust and water protection
- Vibration Rating: 5G per ANSI C136.31
- LED Lifespan: 100,000 hours (L70)
- IES Distribution: Type III optics for roadway and area lighting
- Effective Projected Area (EPA): 2.2
- Mounting: Slipfitter with 180° pivot for 2 3/8" tenon
Features
- Specification-grade optics deliver clean, uniform light distributions
- Replaces 320W metal halide fixtures for energy savings
- Superior thermal management with external air-flow fins for maximum operational life
- Die-cast aluminum housing, lens frame, and mounting arm for durability
- High durability finish formulated for long-lasting color
- Mercury and UV free; RoHS-compliant components
- Two constant current drivers with high power factor and low total harmonic distortion
- 277V swivel photocell included, compatible with 208V-277V systems
- 6kV surge protection tested per IEEE/ANSI standards
- Easy-access electrical compartment for fast and secure wiring
- Industry-leading 5G vibration rating for reliable performance in harsh environments
- 10-year warranty covering light output, color stability, driver performance, and finish
- 3-step MacAdam Ellipse binning for consistent color uniformity
