RWLED3T105SFNRG/PCS2 LED Roadway Lighting

The RWLED3T105SFNRG/PCS2 by RAB is a specification-grade LED roadway lighting fixture designed for efficient, uniform illumination in roadway, general parking, and area lighting applications. This lighting solution replaces traditional 320W metal halide fixtures with a 105W LED system, providing enhanced energy efficiency and long service life. Ideal for electrical distributors and lighting solutions providers, this product supports sustainable infrastructure with mercury and UV-free components and meets rigorous industry standards for performance and durability.

Specifications

• Manufacturer: RAB
• Input Wattage: 108 watts
• Lumens: 12,042 lumens
• Efficacy: 111 lumens per watt
• Color Temperature: 4000 kelvins (Neutral)
• Color Accuracy: 72 CRI
• Lens Material: Tempered Glass
• Weight: 31.0 lbs
• Ambient Temperature Rating: Up to 104°F (40°C)
• Minimum Starting Temperature: -40°C (-40°F)
• IP Rating: IP66 for dust and water protection
• Vibration Rating: 5G per ANSI C136.31
• L70 Lifespan: 100,000 hours
• IES Distribution: Type III
• Housing: Die-cast aluminum housing, lens frame, and mounting arm
• Mounting: Slipfitter with 180° pivot for 2 3/8" tenon
• Effective Projected Area (EPA): 2.2
• Power Factor: 99.6% at 120V, 94.5% at 277V
• THD: 5.9% at 120V, 11.9% at 277V
• Surge Protection: 6kV surge suppression per IEEE/ANSI C62.41.2
• Photocell: 277V swivel photocell included (compatible with 208V-277V)
• Compliance: UL Listed for wet locations, DLC Qualified (DLC Product Code: P00001782)
• Reflector: Specular vacuum-metallized polycarbonate
• Gaskets: High-temperature silicone
• Finish: Durable gray finish formulated for long-lasting color
• Green Technology: Mercury and UV free, RoHS-compliant components

Features

• Replaces 320W metal halide fixtures with a 105W LED for energy savings
• Specification-grade optics with factory-installed Type III distribution for uniform light and minimal glare
• Superior thermal management with external air-flow fins for maximum operational life in high ambient temperatures
• Industry-leading 5G vibration rating for durability in demanding environments
• Easy-access electrical compartment for fast, secure wiring
• 27-year lifespan reduces maintenance and re-lamping costs
• 10-year warranty covering light output, color stability, driver performance, and fixture finish
• Slipfitter mounting with 180° pivot for versatile installation on 2 3/8" tenon poles
