RWLED2T50SFYW
SKU: #115303
Part: #RWLED2T50SFYW
UPC: 019813184951
RWLED2T50SFYW
SKU: #115303
Part: #RWLED2T50SFYW
UPC: 019813184951
Description
RWLED2T50SFYW LED Roadway Lighting
The RWLED2T50SFYW is a specification-grade LED roadway lighting fixture designed for efficient and uniform illumination of entrance roadways, collector roads, and single-sided narrow streets. It provides a reliable lighting solution suitable for electrical distributors and lighting solutions providers focusing on outdoor wire and cable applications and switchgear supplier environments requiring durable, high-performance fixtures.
Specifications
- Manufacturer: RAB
- Input Wattage: 55 watts
- Lumens: 6,703 lumens
- Efficacy: 120 lumens per watt
- Color Temperature: 3000 kelvins (Warm)
- Color Accuracy: 71 CRI
- Lens Material: Tempered Glass
- Ambient Temperature Rating: 104°F (40°C)
- Minimum Starting Temperature: -40°C (-40°F)
- Weight: 32 lbs
- IP Rating: IP66 for dust and water protection
- Vibration Rating: 5G per ANSI C136.31
- LED Lifespan: 100,000 hours (L70)
- Driver Type: Constant Current, Class 2, 1400mA, 100-277V, 50-60Hz
- Power Factor: 99.6% at 120V, 96% at 277V
- THD: 6.1% at 120V, 9.4% at 277V
- Effective Projected Area (EPA): 2.2
- Mounting: Slipfitter with 180° pivot for 2 3/8" tenon
- Reflector: Specular vacuum-metallized polycarbonate
- Gaskets: High-temperature silicone
- Housing: Die-cast aluminum housing, lens frame, and mounting arm
- Recommended Mounting Height: Up to 15 ft
- BUG Rating: B1 U0 G1
- DLC Qualified: Yes (DLC Product Code: P00001787)
- UL Listed: Suitable for wet locations as a downlight
Features
- Specification-grade optics delivering efficient, clean, uniform light distributions with IES Distribution Type II
- Replaces 200W metal halide roadway fixtures with 50W LED technology
- Superior thermal management with external Air-Flow fins for maximum operational life even in high ambient temperatures
- Industry-leading 5G vibration rating ensuring durability in demanding environments
- Easy-access electrical compartment for fast and secure wiring
- Precision optics maximize downward street-side lumens with minimal glare
- 10-year no-compromise warranty covering light output, color stability, driver performance, and finish
- 3-step MacAdam Ellipse binning for consistent fixture-to-fixture color
- LED color temperature warranted to shift no more than 200K over 5 years
- Surge protection: 6kV tested per IEEE/ANSI C62.41.2
- Compliant with Buy American Act (BAA) upon request
