RWLED2T50SFW LED Roadway Lighting

The RWLED2T50SFW is a specification-grade LED roadway lighting fixture designed for efficient, uniform illumination of entrance roadways, collector roads, and single-sided narrow lighting applications. It is suitable for electrical distributors and lighting solutions providers focusing on durable and energy-efficient outdoor lighting. This fixture offers high-performance lighting with a 50W LED input wattage, replacing traditional 200W metal halide fixtures, making it ideal for wire and cable installations in street lighting and compatible with switchgear suppliers’ outdoor setups.

Specifications

• Manufacturer: RAB
• Input Wattage: 56 watts
• Lumens: 7,070 lumens
• Efficacy: 126 lumens per watt
• Color Temperature: 5000 kelvins (Cool)
• Color Accuracy: 71 CRI
• Lens Material: Tempered Glass
• Ambient Temperature Rating: 104¬∞F (40¬∞C)
• Minimum Starting Temperature: -40¬∞C (-40¬∞F)
• Product Weight: 32 lbs
• IP Rating: IP66 for dust and water protection
• Vibration Rating: 5G per ANSI C136.31
• LED Lifespan: 100,000 hours (L70)
• IES Distribution: Type II
• Effective Projected Area (EPA): 2.2
• Driver Type: Constant Current, 100-277V, 50-60Hz, Power Factor 99%
• Surge Protection: 6kV surge suppression per IEEE/ANSI C62.41.2
• Mounting: Slipfitter with 180¬∞ pivot for 2 3/8" tenon

Features

• Specification-grade optics delivering clean, uniform light distribution with minimal glare
• Replaces 200W metal halide fixtures with lower wattage LED technology
• Die-cast aluminum housing with durable finish for long-lasting performance
• Superior thermal management with external air-flow fins for maximum operational life
• High durability tempered glass lens
• 7-step MacAdam Ellipse binning for consistent color fixture-to-fixture
• Easy-access electrical compartment for fast and secure wiring
• Industry-leading 5G vibration rating for reliability in demanding environments
• 10-year warranty covering light output, color stability, driver performance, and fixture finish
• DLC qualified for energy rebates
• Compliant with wet location requirements as a downlight
