Description
Features
- Sealing Sleeves on Conduit Side of Hub
- Molded PVC Gasket Seals Flush with Enclosure Wall
- O-Ring Gasket Provides Additional Seal
- Used to Terminate Conduit Runs Through the Wall of a Sheet Metal Electrical Enclosure
Additional Information
- Maximum Wall Thickness 0.25 Inch
- Seal Type O-Ring Gasket
- Enclosure Rating Class I Div 2, Class II Div 1 and 2, Class III Div 1 and 2
- Applicable Standard ISO 9001, NEC/CEC
Specifications
- Trade Size: 4 Inch
- Size: 6.25 Inch Diameter
- Constructional Feature: NEMA 2/3/3R/4/4X/11/12
- Material: 2 Mil Red Urethane (Interior)/40 Mil Gray PVC Coated (Exterior) Ferrous Metal
- Approval: UL (Canada and US), UL 514B
- Used On: ST Style Conduit
- Series/Model: ST
- Weight: 3.500 lbs
Downloads
Specification/TechnicalCatalog
Data Sheet
Other 1
Other 2
Other 3
Catalog
Installation/Operator
More Information
Manufacturer Catalog Number
PRST10
Weight
3.5000
Material
Steel
Color
Red;Grey
Outside Diameter
6.250000000000000 in
Type
FITTING
