Remote Enclosed Electronic Transformer for InvisiLED Tape Light 120V Input 24V Output 100 Watt

This UL and cUL listed class 2 enclosed electronic transformer is designed for wiring multiple low voltage fixtures, making it suitable for electrical distributors and lighting solutions providers specializing in wire and cable and switchgear supply. It provides a 120V input and 24V output at 100 watts, optimized for low voltage LED tape lighting applications such as InvisiLED. The transformer features compartmentalized class 2 outputs for enhanced safety, allowing no more than 5 amps per compartment. It supports dimming with electronic low voltage dimmers and has a low minimum load requirement of 1 watt, enabling compatibility with LED products. The enclosure is constructed from aluminum with a black finish and includes knockouts on three sides for line voltage wiring.

Specifications

• Manufacturer: WAC Lighting
• Manufacturer Part #: EN-24100-RB2-T
• Input Voltage: 120 Vac
• Output Voltage: 24 Vac
• Power Rating: 100 Watt
• Maximum Load: 60 W
• Minimum Load: 1 W
• Input Current: 0.6 A max
• Operating Temperature Range: -20ºC to 50ºC (-4ºF to 122ºF)
• Material: Aluminum
• Finish: Black
• Dimmable: Yes (electronic low voltage dimmer compatible)
• Product Weight: 0.91 lbs

Features

• Class 2 enclosed transformer with compartmentalized outputs for safety
• UL and cUL listed
• Electronic short circuit protection with auto-reset
• Overload protection with auto-reset
• Automatic thermal regulation
• Soft start delay to preserve bulb life (compatible with tungsten filament lamps)
• Knockouts on three sides with clips for line voltage wiring
• Secondary wiring does not require conduit-sheathed cable or clamp wiring
• Low minimum load of 1W supports LED lighting
• Enclosure cover is easily removable for installation and service
