Remke Industries
REMINGTON RTK-125-8 MC CABLE CONNECTOR, ALUM, 1-1/4IN NPT, RANGE OVER JACKET 1.350 - 1.475, RANGE OVER ARMOR 1.240 - 1.395
SKU: #402401
Part: #RTK-125-8
UPC: 785411817347
Remke Industries
REMINGTON RTK-125-8 MC CABLE CONNECTOR, ALUM, 1-1/4IN NPT, RANGE OVER JACKET 1.350 - 1.475, RANGE OVER ARMOR 1.240 - 1.395
SKU: #402401
Part: #RTK-125-8
UPC: 785411817347
Description
REMINGTON RTK-125-8 MC Cable Connector, Aluminum, 1-1/4IN NPT
The REMINGTON RTK-125-8 MC Cable Connector by Remke Industries is a one-piece aluminum connector designed for use with metal-clad (MC) cables. It provides a watertight seal around the jacketed cable and at the enclosure entry, making it suitable for electrical distributors, lighting solutions, wire and cable installations, and switchgear applications. This connector supports cable jacket diameters ranging from 1.350 to 1.475 inches and armor diameters from 1.240 to 1.395 inches. Its compact design enables installation in tight spaces without disassembly, enhancing efficiency in electrical distribution systems.
Specifications
- Material: Aluminum
- Color: Ivory
- Length: 4.23 in
- Width: 2.97 in
- Height: 2.97 in
- Hub Size: 1 1/4 inch NPT
- Cable Range Over Jacket: 1.350 - 1.475 in
- Cable Range Over Armor: 1.240 - 1.395 in
- Product Weight: 0.0560 lb
- Manufacturer: Remke Industries
- Manufacturer Part #: RTK-125-8
- UPC: 785411817347
- Ratings: NEMA 4, IP65
Features
- Exclusive one-piece PowR-Lock™ design for superior grounding and conductivity
- No disassembly required for fast, simple installation
- Neoprene bushing provides superior pull-out resistance and sealing protection
- Embedded Buna-N O-ring (Viton® available) ensures watertight and chemical-resistant termination
- Compact size allows installation in tight spaces and closer spacing in electrical panels
- Meets UL and CSA standards for raintight metal-clad cable fittings
- Made in the USA
