Reducing Adapter for 750 kcmil Barrel Reducing down to 500 kcmil CU – Wire Reducing Splice Adapter

This copper reducing adapter is designed for electrical distributors and switchgear suppliers requiring reliable wire and cable splice solutions. It facilitates the connection of a larger 750 kcmil copper conductor to a smaller 500 kcmil conductor by providing a long barrel, tin-plated compression splice reducer. The adapter is suitable for applications up to 35,000 volts and is color-coded black for easy identification.

Specifications

• Application: Wire Reducing Splice Adapter Insert
• Material: Copper
• Conductor Material: Copper
• Connection Type: Long Barrel
• Max. Voltage: 35,000 volts
• Finish: Tin-Plated
• Color Coding: Black
• Width: 1.02 in
• Length Overall: 2.88 in
• Inside Diameter: 0.83 in
• Outside Diameter: 1.017 in
• Die Index: 24
• Product Weight: 0.2300 lbs
• Made in USA: Yes
• Manufacturer Part #: Y3934R

Features

• Copper reducing sleeve allows a larger terminal or splice to accommodate a smaller wire gauge
• Internal chamfer for easier wire insertion
• Tin-plated finish for enhanced corrosion resistance
• Designed to reduce 750 kcmil copper conductor size down to 500 kcmil
• Suitable for use in high voltage applications up to 35kV
