Features

• For use with a 6.00” to 6.12” Drilled or Formed Concrete Round Hole
• Up to 2 Hour Fire Rating
• Step Down Installation
• (4) 20A, pre-wired receptacles

Specifications

• Country of Origin: Puerto Rico
• Application - For Use On: Concrete
• Core Hole: 6 Inch
• Width: 8.400 in
• Each - Width: 8.400 in
• Industry Standard(s): cULus Listed;Meets ADA Standards;UL 514A Listed
• Plate Style: Accepts S1R6xx Series
• Size: Standard Sized Product
• Application: 6" Fire-Rated Poke-Through Series
• Cable Entry: Through Cover
• Color: Black
• Finish: Black Powder Coat Cover
• Mounting: 6" Core Hole
• Number of Outlet: (2) 50% Left Side Sub Plates- (3) Extron® AAP Opening, (5) Extron® MAAP Opening, 50% Left Side, (1) Style Line® Decorator Opening, (2) Hubbell Keystone Openings and (1) 50% Left Side Sub Plate- (1) Style Line® Decorator Opening, (2) Hubbell Keystone Openings
• Special Features: (4) 20A, pre-wired receptacles
• Standard: cULus Listed;Meets ADA Standards;UL 514A Listed
• Sub Brand: SystemOne Recessed
• Type: 6" Recessed Rated Poke Through Kit
• Accessory Type: 6" FRPT Kit
• Finish Type: Black Powder Coat Cover
• Mounting Type: 6" Core Hole
• Number Of Outlets: (2) 50% Left Side Sub Plates- (3) Extron® AAP Opening, (5) Extron® MAAP Opening, 50% Left Side, (1) Style Line® Decorator Opening, (2) Hubbell Keystone Openings and (1) 50% Left Side Sub Plate- (1) Style Line® Decorator Opening, (2) Hubbell Keystone Openings
• Style: FRPT - Complete Kits
• Description - Invoice: S1R FRPT 6 4x20A, EXTR M+AAP,STY+2KS BLK
• Freight Class Code: 06168002
• Harmonization Code: 8536698000
• Image Actual Or Representative: A
• MSDS Flag: No
• Material - Mounting Hardware: Mounting Hardware Included
• Material: Fabricated
• Base Unit of Measure: EA
• BOX SIZE: 10.700x12.700x9.300 (in)
• Carton - SCC-14 Next Lower Level Sub Pack: 00783585443355
• Case Weight: 10.550 lb.
• Each - Pack Description: Each
• Lowest Level UOM: Each

Certifications

• EU RoHS Indicator: Contact Manufacturer

Downloads
