R2R8930120WB LED Downlight – Lighting Solutions for Electrical Distributors

The R2R8930120WB is a high-performance LED downlight designed for residential and commercial lighting applications. It offers efficient illumination with a warm 3000K color temperature and a narrow 38° beam angle, suitable for accent lighting. This product is ideal for electrical distributors and lighting solution providers looking for reliable, energy-efficient fixtures compatible with 120V systems.

Specifications

• Manufacturer: RAB
• Input Voltage: 120 volts
• Input Wattage: 8 watts
• Lumens: 623 lumens
• Efficacy: 81 lumens per watt
• Color Temperature: 3000 kelvins (Warm)
• Color Accuracy: 90 CRI
• Lens Material: Diffuse Polystyrene
• Product Weight: 0.4 lbs
• Minimum Starting Temperature: -22 degrees Fahrenheit
• Maximum Ambient Temperature: 35 degrees Celsius
• Beam Angle: 38¬∞ narrow beam spread
• LED Lifespan: 50,000 hours
• Power Factor: ‚â•0.9

Features

• UL Listed and suitable for wet locations
• ENERGY STAR¬Æ Version 2.2 Certified
• NEC compliant for use in closets
• California Title 24 compliant
• TRIAC compatible dimmer with dimming as low as 5%
• Robust die-cast metal driver and junction box with hinged cover
• IC Rated for direct contact with insulation (not for spray foam insulation)
• Air Tight housing certified to ASTM E283 standards
• Matte white finish with baffle trim style
• Spring-loaded retention clips for secure mounting in ceilings 1/4" to 1 1/2" thick
• Mercury and UV free, RoHS-compliant components
• Silent, flicker-free operation with less than 30% flicker
• 5-year warranty covering light output, color stability, driver performance, and finish

Downloads & Links

• Spec Sheet
• Photometrics Report
• Instructions
• Cut Out Template
• Compatibility List
