Push-In Wire Connectors 8 Pole Hanging Bag 25 Pack - Push-In Wire Connectors

Push-In Wire Connectors provide a fast and effective alternative to traditional wire nuts for electrical distributors and lighting solutions providers. Designed for easy installation, these connectors accept both stranded and solid conductors, reducing installation time and repetitive motion fatigue. Ideal for applications in junction boxes, control panels, security/alarm systems, prefabricated wiring systems, and lighting retrofits.

Specifications

• Manufacturer: Morris Products
• Manufacturer Part #: 23228
• Poles: 8
• Color: Black
• Voltage Rating: 600V
• Current Rating: 24 Amps
• Wire Range: 18-14 AWG stranded, 20-14 AWG solid
• Dimensions (L x W x H): 0.748 in x 0.689 in x 0.661 in
• Material: Polycarbonate housing with UL 94V-2 flame retardant rating
• Working Temperature: 221°F (105°C)
• UL Listed for Copper Conductors only
• Product Weight: 0.0160 lbs

Features

• Push-in design eliminates twisting or taping, allowing quick and safe wire connections
• Low wire insertion force for fast, easy connections
• No-twist connection reduces repetitive motion fatigue
• See-thru housing for visual inspection of connections
• Test port included for continuity testing
• Electrolytic tin-plated copper internal bus for high conductivity
• UL listed and compliant with safety standards for electrical wiring
