Power Protection Products, GFCI,Receptacle, Blank Face, 20A 125V, HP Rated, Brown
SKU: #140530
Part: #GFBFHP20
UPC: 883778450006
Power Protection Products, GFCI,Receptacle, Blank Face, 20A 125V, HP Rated, Brown
SKU: #140530
Part: #GFBFHP20
UPC: 883778450006
Description
Power Protection Products GFCI Receptacle Blank Face 20A 125V HP Rated Brown
This GFCI protection device from Hubbell Wiring Device-Kellems is designed for electrical distributors and switchgear suppliers requiring reliable ground fault circuit interruption. It serves as a blank face receptacle rated for 20 amperes and 125 volts, suitable for applications demanding HP-rated power protection. The device is constructed from composite material and features insulated connections per UL standards, ensuring safety and durability in dry indoor environments unless additional protection is applied.
Specifications
- Application: GFCI Protection
- Current: 20 amperes
- Amperage Rating: 20.000000000000000 A
- Voltage Rating: 125 V
- Material: Composite
- Color: Brown
- Width: 3.1 in
- Mounting: Mounting Screw
- Connection: Terminal Screws
- Number of Wires: 3
- Insulation: Insulated per UL
- Dielectric Strength: 1500 volts between (line H to load H), (line H to face H), (line N to load N) and (line N to face N)
- NEMA Rating: None - Blank Face
- Product Weight: 3.9 lbs
- Country of Origin: China
- Manufacturer: Hubbell Wiring Device-Kellems
- Manufacturer Part #: GFBFHP20
Features
- HP rated for motor loads
- Blank face design for specific GFCI protection applications
- UL insulated connections for enhanced safety
- Terminal screw connections for secure wiring
- Mounting screw installation for straightforward assembly
