Power Protection Devices, Receptacle, Self Test, GFCI, 20A 125V, 2-Pole 3-Wire Grounding, 5-20R, Brown
SKU: #140834
Part: #GFRST20
UPC: 883778122125
Power Protection Devices, Receptacle, Self Test, GFCI, 20A 125V, 2-Pole 3-Wire Grounding, 5-20R, Brown
SKU: #140834
Part: #GFRST20
UPC: 883778122125
Total Price: $17.29 per each Sold in increments of 1 each
Description
Power Protection Devices, Receptacle, Self Test, GFCI, 20A 125V, 2-Pole 3-Wire Grounding, 5-20R, Brown GFCI Receptacle
This commercial grade Power Protection Device is a ground fault circuit interrupter (GFCI) receptacle designed for electrical distributors and lighting solutions requiring reliable ground fault protection. It is rated for 20 amperes at 125 volts, with a 2-pole, 3-wire grounding configuration and a NEMA 5-20R rating. The device is suitable for indoor dry environments unless additional protection is provided.
Specifications
- Manufacturer: Hubbell Wiring Device-Kellems
- Manufacturer Part #: GFRST20
- Application: Commercial Grade
- Amperage Rating: 20 A
- Current: 20 amperes
- NEMA Rating: 5-20R
- Number of Poles: 2-Pole
- Number of Wires: 3-Wire Grounding
- Voltage: 125 V
- Material: Thermoplastic/Composite
- Color: Brown
- Width: 2.048 in
- Mounting: Mounting Screws
- Connection: Terminal Screws
- Product Weight: 0.1700 lbs
- Country of Origin: China
- Environmental Conditions: Indoor Dry unless protected by additional means
Features
- Self-test functionality ensures continuous ground fault protection without manual testing.
- Patented AUTOGUARD® technology for automatic self-testing and power disconnection if protection is lost (referenced in NEC 210.8 requirements).
- Clear visual indicators provide status on power, trip condition, ground fault condition, and end-of-life.
- Designed to comply with NEC 2017 code changes for GFCI protection in commercial and residential branch circuits.
- Suitable for branch circuits requiring GFCI protection in crawl spaces, unfinished basements, garages, and other specified locations.
- Constructed with durable thermoplastic/composite materials for commercial-grade reliability.
Downloads & Links
- 017 NEC® Code Changes Guide
- Catalog Full Asset Reference
- Sales Drawing Asset Reference
- Pulp & Paper Solutions
- Catalog Page Asset Reference 1
- Spec Sheet
- Catalog Page Asset Reference 2
- Installation Manuals Asset Reference
- Warranty Document Asset Reference
- GFRST20 AutoCAD Drawing
- AUTOGUARD® Self Test Ground Fault Receptacles
