Polaris™ Ins Multi-Tap 750 4 Port DSE Wire Termination Connector

The Polaris™ Ins Multi-Tap 750 4 Port Dual Side Entry connector is designed for wire termination applications, offering reliable electrical connections for wire and cable systems. Manufactured by NSI Industries, this insulated multi-cable connector is suitable for use with Class B and C copper or aluminum conductors, making it an effective solution for electrical distributors and lighting solutions requiring robust wire management. Its dual entry design allows wiring access from both sides, enhancing installation flexibility in switchgear and electrical distribution setups.

Specifications

• Application: Wire Termination
• Manufacturer Part #: IPLD750-4
• Material: Aluminum (6061-T6 alloy)
• Finish: Plastisol Insulated
• Color: Black
• Number of Conductors: 4
• Number of Poles: 1
• Wire Type: Class B & C
• Environmental Conditions: Rated for 90°C, cold temperature rated to -45°C
• Dimensions (L x W x H): 6.38 in x 3.41 in x 3.42 in
• Product Weight: 0.9350 lbs
• Voltage Rating: 600V

Features

• Dual side entry with removable caps for flexible wire access
• Pre-filled with oxide inhibitor for enhanced conductivity and corrosion resistance
• High dielectric strength plastisol insulation provides abrasion, chemical, and UV resistance
• UL 486B listed for copper or aluminum Class B and C conductors
• Eliminates the need for additional insulation tape or covers
• Suitable for harsh vibration-prone environments
• Cold temperature rated to -45°C for extended environmental durability
• UV resistant black plastisol finish
• 3/8 inch internal hex pressure screw for secure connections
