PMCPL-500, Conduit Coupling – PVC-Coated Electrical Conduit Coupling

The PMCPL-500 conduit coupling is designed to connect coated conduit sections while maintaining electrical continuity across assembled joints. This product is suitable for electrical distributors and switchgear suppliers requiring reliable conduit connections in lighting solutions and wire and cable installations. Its galvanized steel construction with a dual-layer coating provides corrosion resistance and durability in various electrical applications.

Specifications

• Application: Connects coated conduit sections while maintaining electrical continuity across assembled joints
• Material: Galvanized Steel
• Finish: 2 mil green urethane interior coating; 40 mil gray PVC exterior coating
• Trade Size: 5 Inch
• End Type: Threaded (Straight Tapped)
• Threads Per Inch: 8
• Inside Diameter: 5.000 in
• Outside Diameter: 6.080 in
• Length: 18.5 in
• Width: 12.25 in
• Height: 8 in
• Product Weight: 5.44 lbs
• Standard Package: 4 per Pack
• Approvals: UL (Canada and US), UL 6, CSA C22.2
• Applicable Standard: ISO 9001
• Manufacturer: Perma-Cote
• Manufacturer Part #: CPL-500
• Color: Green (interior); Gray (exterior)

Features

• 40 mil gray PVC exterior coating prevents corrosion and environmental damage
• 2 mil green urethane interior coating over galvanized threads ensures electrical continuity and thread protection
• Sealing PVC sleeves overlap conduit ends to prevent corrosive liquids and vapors from attacking threaded joints
• Couplings are straight tapped for secure and consistent threading
• Complies with UL 6 (E2314), UL 6A (E98405), and CSA C22.2 No. 45 standards
