PMCPL-200 Conduit Coupling – PVC-Coated Electrical Conduit Connector

The PMCPL-200 conduit coupling is designed to connect coated conduit sections while maintaining electrical continuity across assembled joints. This product is suitable for electrical distributors and switchgear suppliers requiring reliable conduit connections with corrosion protection. It features a galvanized steel construction with dual coating for enhanced durability in electrical and lighting solutions involving wire and cable installations.

Specifications

• Application: Connects coated conduit sections while maintaining electrical continuity across assembled joints
• Trade Size: 2 Inch
• End Type: Threaded
• Material: Galvanized Steel
• Finish: 2 Mil Green Urethane (Interior/Thread), 40 Mil Gray PVC Coated (Exterior)
• Threads Per Inch: 11-1/2
• Type: Straight Tapped
• Inside Diameter: 2.000 in
• Outside Diameter: 2.969 in
• Dimensions (L x W x H): 18.5 in x 12.25 in x 8 in
• Product Weight: 0.96 lbs
• Standard Package: 30 per Pack
• Certifications: UL (Canada and US), UL 6, CSA C22.2, ISO 9001

Features

• 40 mil gray PVC exterior coating prevents corrosion and environmental damage
• 2 mil green urethane interior coating over galvanized threads ensures electrical continuity and thread protection
• Sealing PVC sleeves on both ends overlap conduit to prevent corrosive liquids and vapors from attacking threaded joints
• Couplings are straight tapped for secure, reliable connection
• Complies with UL 6, UL 6A, and CSA C22.2 standards
