Features

• .036 inch thick, brass, triple-wipe power contacts for lasting retention.
• Available in 'SP' series in Standard, Junior-Jumbo, and Jumbo sizes.
• No exposed terminals create a finger safe application before, during, and after installation.
• Built-in connector features large brass terminal blades to ensure consistent, reliable electrical connections.
• Crimped and welded contacts.
• Ultrasonically welded polycarbonate connector housing secures terminations and conductors in a UL Listed, finger safe housing.
• Pre-stripped connector leads fasten to conductors, easier than standard pigtails.
• Auto-ground clip assures positive ground.
• For covering patents, see www.legrand.us/patents.
• Temperature Rise: Maximum 30°C temperature rise at full-rated current after 50 cycles of overload at 150% of rated current with direct current. Operating Temperature: Maximum continuous +60°C, minimum -40°C without impact
• PlugTail™ Connector: #12 AWG, THHN, copper conductor, 6"" leads, stripped, solid or stranded, for use with PlugTail Receptacles only

Certifications

• cULus Listed
• Federal Spec Listed

Specifications

• Color: Gray
• Finish: Matte
• Product Line: Pass & Seymour

Specifications

• Depth: 0.9 in
• Height: 3.281 in
• Width: 1.625 in
• Country of Origin: United States
