Features

• Available in multiple sizes
• For use on Rapid Start, Instant Start (40W), Electronic and dimming curcuits
• Light output comparable to a 32W 4' fluorescent
• 90% lumen maintenance
• 82 CRI or higher
• Available in18,24,36,40,50,55,and 80 watts with 3000,3500,4100,5000 color temperatures (5000K color temperature is only available in 55W)
• Just 1.4mg of mercury

Benefits

• PL-L offers long life in a sleek profile.
• Available in a broad range of color temperatures.
• 24 month warranty

Applications

• perfect for 2' x 2' fixtures in office and healthcare facilities.

Warning And Safety

• Lamp contains mercury. Manage in Accord with Disposal Laws. See: www.lamprecycle.org or 1-800-555-0050

Specifications

General Information

• Base: 2G11 [ 2G11]
• Life to 50% Failures (Nom): 10000 h
• System Description: Rapid Start (RS)

Light Technical

• Color Code: 841 [ CCT of 4100K]
• Initial lumen (Nom): 4000 lm
• Color Designation: Cool White (CW)
• Lumen Maintenance 10000 h (Nom): 91 %
• Lumen Maintenance 2000 h (Nom): 94 %
• Lumen Maintenance 5000 h (Nom): 91 %
• Correlated Color Temperature (Nom): 4100 K
• Luminous Efficacy (rated) (Nom): 80 lm/W
• Color Rendering Index (Nom): 82

Operating and Electrical

• Power (Rated) (Nom): 50.0 W
• Lamp Current (Nom): 0.430 A
• Voltage (Nom): 150 V

Controls and Dimming

• Dimmable: Yes

Mechanical and Housing

• Cap-Base Information: 4P
