Features

• Ultra-high efficiency
• DLC Premium
• 0-10V Dimming, standard
• 60,000-Hour LED lifespan
• 5-Year, Limited Warranty
• Equivalency
• 5 Yr Limited Warranty
• Buy American Act Compliance

Specifications

• Weight: 20.6 lbs

Compliance

• UL Listed: Suitable for wet locations. Suitable for ground mounting.
• IESNA LM-79 & LM-80 Testing: RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
• DLC Listed: This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.

Performance

• Watts: 70W
• Color Temp: 5000K (Cool)
• Lumens: 11,191 lm
• Efficacy: 156 lm/W
• Color Accuracy: 74 CRI
• Type: Constant Current
• 120V: 0.60A
• 208V: 0.34A
• 240V: 0.30A
• 277V: 0.26A
• Input Watts: 72W

LED Characteristics

• LEDs: Long-life, high-efficacy, surface-mount LEDs
• Color Uniformity: RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Construction

• IP Rating: Ingress protection rating of IP66 for dust and water
• Thermal Management: Superior thermal management with external "Air-Flow" fins
• Maximum Ambient Temperature: Suitable for use in up to 40°C (104°F)
• Cold Weather Starting: The minimum starting temperature is -30°C (-22°F)
• Housing: Precision die-cast aluminum housing
• Lens: Two (2) clear acrylic lens with integrated optics
• Mounting: Heavy-duty slipfitter for 2 3/8"OD pipe
• Effective Projected Area: EPA = 1.4
• Gaskets: High-temperature silicone gaskets
• Green Technology: Mercury and UV free. RoHS-compliant components.
• Finish: Formulated for high durability and long-lasting color
• Tilt Increment: Rotates in 6 degree increments

Electrical

• Driver: Constant Current, Class 2, 120-277V, 50/60Hz, 120V: 0.60A, 208V: 0.34A, 240V: 0.30A, 277V 0.26A
• Dimming Driver: Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
• THD: 3.74% at 120V, 8.54% at 277V
• Power Factor: 99.9% at 120V, 96.7% at 277V
• Surge Protection: 4kV
• Note: All values are typical (tolerance +/- 10%)
