PIP30/D10 LED Flood Light – Lighting Solutions for Electrical Distributors

The PIP30/D10 by RAB is a high-performance LED flood light designed for outdoor architectural and security lighting applications. It delivers efficient illumination with a luminous output of 4,400 lumens at an input wattage of 31 watts, providing an efficacy of 144 lumens per watt. Suitable for electrical distributors and lighting solution providers, this fixture offers reliable performance in a variety of environments, meeting the needs of wire and cable suppliers and switchgear suppliers requiring durable and energy-efficient lighting.

Specifications

• Manufacturer: RAB
• Model Number: PIP30/D10
• Lumens: 4,400 lumens
• Input Wattage: 31 watts
• Efficacy: 144 lumens per watt
• Color Temperature: 5000 kelvins
• Color Accuracy (CRI): 75
• Lens Material: Frosted Acrylic
• Ambient Temperature Rating: 104 °F
• Minimum Starting Temperature: -40 °C
• Product Weight: 3.7 lbs
• UPC: 019813494807

Features

• High luminous output with energy-efficient LED technology
• Durable frosted acrylic lens for optimal light diffusion
• Wide operating temperature range for versatile outdoor use
• Compatible with 120V to 277V power supply for flexible installation
• 0-10V dimmable driver for controllable lighting levels
• Robust design suitable for architectural flood and spot lighting
• Designed for easy installation on weatherproof junction boxes or ground mounts

Downloads & Links

• Instructions
• LM79
• Spec Sheet
